Orbis
Roberto Mantovani - Paolo Francescato
A disc of light, a pure form subtly extending forward, conceals a secret within its finely crafted glass-bringing light to life with shifting vibrancy as the viewing angle changes. Both essential and dynamic, it is a perfectly functional object, elevated by meticulous attention to detail.
METAL COLOR
GLASS COLOR
Dry location
0 -10V, IGBT-TRIAC, ELV
CRI90
UPORBIS32XXXXD1
UPORBIS32XXXXD2
UPORBIS44XXXXD1
UPORBIS44XXXXD2
UPORBIS60XXXXD1
UPORBIS60XXXXD2
DOWNLOAD
| CCT | Ø32,2cm 12,7" 11W | Ø44cm 17,3" 24W | Ø60,5cm 23,8" 48W | |
|---|---|---|---|---|
| 2700K | 1170lm | 2250lm | 4500lm | |
| 3000K | 1300lm | 2500lm | 5000lm | |
| 3500K | 1469lm | 2825lm | 5650lm |
| CCT | 2700K |
| Ø32,2cm 12,7" 11W | 1170lm |
| Ø44cm 17,3" 24W | 2250lm |
| Ø60,5cm 23,8" 48W | 4500lm |
| CCT | 3000K |
| Ø32,2cm 12,7" 11W | 1300lm |
| Ø44cm 17,3" 24W | 2500lm |
| Ø60,5cm 23,8" 48W | 5000lm |
| CCT | 3500K |
| Ø32,2cm 12,7" 11W | 1469lm |
| Ø44cm 17,3" 24W | 2825lm |
| Ø60,5cm 23,8" 48W | 5650lm |
| SOURCE | SUPPLY | LED DRIVER | ||
|---|---|---|---|---|
| LED | 120-277VAC | Included |
| SOURCE | LED |
| SUPPLY | 120-277VAC |
| LED DRIVER | Included |
CODE
Build your code by choosing each attribute
UPORBIS
